General Electric WD12X10244 Dishwasher Base Spray Arm

Special Price $73.59 Regular Price $75.95
In stock
Available Quantity:   92
SKU
WD12X10244

Product Description

The General Electric WD12X10244 Dishwasher Base Spray Arm is used to distribute water in the lower section of the appliance. Its operation is based on rotation and spraying water around dishes in the wash cycle to cover the items on the lower rack. The spray arm is securely fixed to the bottom of the dishwasher and is in line with the water supply and other parts. It can be installed in the lower compartment and can be turned properly, and water can flow through it, yet it fits in the internal structure of the dishwasher.
Arm,
Manufacturer
https://www.hnkparts.com/media/catalog/product/w/d/wd12x10244_general-electric_hnkparts.png

This Part Fits the Following Models (426)

Hotpoint HDA3600K55BB Dishwasher Hotpoint HDA3600K55WW Dishwasher Hotpoint Hotpoint HDA2100H65BB Dishwasher HotPoint HDA3600N00BB Dishwasher Hotpoint HDA3600N00CC Dishwasher Hotpoint HDA3600N00WW Dishwasher Hotpoint HDA3600N10BB Dishwasher Hotpoint HDA3600N10CC Dishwasher Hotpoint HDA3600N10WW Dishwasher Hotpoint HDA3600N20BB Dishwasher Hotpoint HDA3600N20CC Dishwasher Hotpoint HDA3600N20WW Dishwasher Hotpoint HDA3600R00BB Dishwasher Hotpoint HDA3600R00CC Dishwasher HotPoint HDA3600R00WW Dishwasher
Showing 1-15 of 426
Manufacturer Name: GENERAL ELECTRIC
Product Number: WD12X10244
OEM Part Number: WD12X10244
Product Description: Base Spray Arm

Choose the best Home Appliance parts and supplies from HnKParts!

  • Same Day Shipping

  • Best Quality And Best Price

  • Wide Range of Inventory

  • Best Customer Service

Have More Questions or Need Help to Place The Order?
Reach us at (866)723-0907 or [email protected]

Write Your Own Review
You're reviewing:General Electric WD12X10244 Dishwasher Base Spray Arm
Your Rating
Customer Questions
No Questions

Installation Steps

Step 1: The dishwasher should be disconnected from the power source and the water supply should be turned off.

Step 2: The lower rack should be taken out to provide access to the lower spray arm.

Step 3: A flathead screwdriver should be employed to take off the upper screws that hold the spray arm support base in place.

Step 4: The spray arm should be raised and removed from the support base, granting access to the lower spray arm support base underneath.

Step 5: The fasteners found at the support base should be unscrewed to completely detach it from the dishwasher.

Step 6: The new lower spray arm support base should be positioned with the mounting holes. Proper alignment should be ensured before it is fastened securely.

Step 7: The new base should be fastened using the upper screws that were previously removed.

Step 8: The lower spray arm should be reinserted and secured using the screws from the original support base.

Step 9: The lower rack should be reinstalled and the dishwasher should be reconnected to the power supply. The water source should be reactivated.

Step 10: The dishwasher should be verified to confirm that the new lower spray arm support base is firmly installed and operating properly.

It is important to note that these instructions are served as general guidance and should always be followed alongside the manufacturer's manual, if one is available.
