General Electric WD01X10340 Dishwasher Spray Arm Bearing

$6.94
In stock
Available Quantity:   26
SKU
WD01X10340

Product Description

BEARING SPRAY ARM
Manufacturer
https://www.hnkparts.com/media/catalog/product/w/d/wd01x10340_general-electric_hnkparts.jpg

This Part Fits the Following Models (425)

GE VDF200PM55BB Dishwasher GE VDF200PM55WW Dishwasher GE MSD2100R20WW Dishwasher GE GSM2260V70SS Dishwasher GE GSM2200N10WW Dishwasher GE GSM2200N15BB Dishwasher GE GSM2200N15WW Dishwasher GE GSM2200V65BB Dishwasher GE GSM2200V65WW Dishwasher GE GSM2200V70BB Dishwasher GE GSM2200V70WW Dishwasher GE GSM2204N10WW Dishwasher GE GSM2260N00SS Dishwasher GE GSM2260N10SS Dishwasher GE GSM2260N15SS Dishwasher
Showing 1-15 of 425
Manufacturer Name: GENERAL ELECTRIC
Product Number: WD01X10340
OEM Part Number: WD01X10340
Product Description: Bearing Spray Arm

Choose the best Home Appliance parts and supplies from HnKParts!

  • Same Day Shipping

  • Best Quality And Best Price

  • Wide Range of Inventory

  • Best Customer Service

Have More Questions or Need Help to Place The Order?
Reach us at (866)723-0907 or [email protected]

Write Your Own Review
You're reviewing:General Electric WD01X10340 Dishwasher Spray Arm Bearing
Your Rating
Customer Questions
No Questions

Installation Steps

Step 1: The GE WD01X10340 Bearing Spray Arm is detached.

To detach the bearing spray arm, the water supply to your appliance is shut off. Next, the dishwasher’s upper spray arm is removed by pressing inward and twisting it counter-clockwise until it is separated. After it is removed, the nut securing the bearing spray arm to the lower spray arm is unscrewed and taken off using a nut driver or a large adjustable wrench.

Step 2: The Bearing Spray Arm is installed.

The new bearing spray arm is found and positioned on the lower spray arm. The nut is reattached with a nut driver or an adjustable wrench, being tightened until it is securely fastened. Finally, the upper spray arm is connected by pressing inward and rotating it clockwise until it is clicked into position.

Step 3: Your repair is verified.

The water supply to the appliance is activated and a cycle is initiated to confirm that the new bearing spray arm operates correctly. If the new bearing spray arm fails to move, adjustment may be required. To adjust the bearing spray arm, a flathead screwdriver is simply used to insert into the existing hole and rotate, either clockwise or counter-clockwise, based on the desired direction for your bearing spray arm to spin.

Congratulations! The GE WD01X10340 bearing spray arm has been successfully replaced.

Please note that these instructions are served as general guidance and should always be referenced alongside the manufacturer's manual, if available.
