main product photo

Viking 12071301 Refrigerator Drain Pan

Be the first to review this product
Special Price $232.20 Regular Price $299.95
In stock
Available Quantity:   1
SKU
12071301

Product Description

The Viking 12071301 Drain Pan serves inside refrigerators to capture both excess condensation and defrost water. The drain pan serves functions by carrying away water leaks and creating a dry, clean interior space in the refrigerator. During the defrost cycle periods, water drains from the evaporator coils into the drainage system, which safely evaporates the water.
Add to Wish List
Refrigerator Parts, Shelfs | Drawers | Baskets,
Manufacturer
https://www.hnkparts.com/media/catalog/product/1/2/12071301.jpg

This Part Fits the Following Models (50)

Showing 1-15 of 50
Write Your Own Review
You're reviewing:Viking 12071301 Refrigerator Drain Pan
Your Rating
FAQS
Customer Questions
What maintenance is required for the Viking 12071301 Drain Pan?

Empty accumulated liquid and wipe the pan clean to prevent blockage. Confirm the pan sits securely under the system. Verify water collects and drains correctly during normal operation without interfering with surrounding components.

What are common issues with the Viking 12071301 Drain Pan?

  • Water pooling inconsistently.
  • Drainage slowing unexpectedly.
  • Pan shifting from position.
  • Overflow occurring during operation.

Installation Steps

Step1: Unplug the refrigerator before beginning the installation process.

Step2: Locate the drain pan at the bottom rear of refrigerator unit.

Step3: Slide out old pan carefully from its mounting position.

Step4: Clean surrounding area to remove debris or spills.

Step5: Insert new drain pan aligning with support rails.

Step6: Restore power and ensure proper drainage operation.
