The Samsung DE81-07744A Range Service Control Board Assembly is a common component found within an electric range to control and manage the cooking capabilities and fits within the control housing of the unit to replace a damaged or worn-out board. It is the main electronic component that controls the temperature, heating element and functioning. It operates by getting and processing the input signals of the control panel, and then sending accurate commands to the heating elements.
Please, mind that only logged in users can submit questions
Installation Steps
Step 1: Prior to starting, it should be confirmed that the new Samsung DE81-07744A SVC-Control Board Assy along with the required tools is possessed. Additionally, it should ensure that protective gear, such as safety glasses or goggles, is available to shield your eyes from dust and debris.
Step 2: The control board should be identified within your appliance. Typically, it is situated at the rear of the unit, beneath any removable covers.
Step 3: All power sources linked to your appliance should be unplugged before commencing work. This step is vital for safety.
Step 4: After the power sources have been disconnected, your Phillips screwdriver should be utilized to take out the screws that secure the old control board assembly. Once the screws are removed, the old assembly should be gently extracted.
Step 5: The new Samsung DE81-07744A SVC-Control Board Assy should be grabbed and placed into the same slot occupied by the old assembly. It should ensure that it is correctly positioned before moving on.
Step 6: After the new control board assembly has been inserted, the Phillips screwdriver should be employed to fasten it securely. It should be confirmed that all screws are properly tightened before advancing.
Step 7: Once the new control board assembly has been installed and secured, the power sources should be reattached to your appliance.
Step 8: After all power sources have been reconnected, your device should be powered on and its operation verified to ensure it functions correctly. If everything seems to be in order, the Samsung DE81-07744A SVC-Control Board Assy has been effectively replaced.
Please remember, these instructions serve as general guidance and should always be followed alongside the manufacturer's manual, if one is available.
