Magic Chef 312180200241 Refrigerator Main PCB MCBC58DST SH103/R3

SKU: 312180200241 4-312180200241 Brand:
Magic Chef
Availability:
In Stock
(2)
$92.64 Price reduced from $93.95
Save $1.31
Have a Question? 866-723-0907

Description

The Magic Chef 312180200241 Refrigerator Main PCB MCBC58DST SH103/R3 is the main electronic component of the appliance and is used to regulate the temperature, the cooling process, and other essential processes of the element. It operates by handling signals sent by sensors and by controlling the parts of the system such as the compressor, evaporator fan and the lights to ensure stable operation. It is mounted inside the control housing and is connected to the wiring harnesses of the unit and which is mounted using the existing hardware. This primary board provides the proper response to temperature, stable operation of the system.

Step1: Unplug the refrigerator to prevent electrical shock.

Step2: Carefully disconnect all wiring connectors from the old PCB.

Step3: Unscrew and remove the old PCB from its mounting.

Step4: Position the new PCB in place and secure with screws.

Step5: Reconnect all wiring, and test the refrigerator for proper operation.

  • What maintenance is required for the Magic Chef 312180200241 Main PCB?

    Keep the PCB area clean, dry, and free from dust. Check all wiring connections are secure and components are properly seated. Proper maintenance ensures accurate temperature regulation and consistent operation of refrigerator systems.

  • What are common issues with the Magic Chef 312180200241 Main PCB?

    • Refrigerator not cooling.
    • Temperature control not responding.
    • Lights or display failing.
    • Ice maker malfunction.

Customer Reviews

5 Based on 2 reviews
5 ★
2
4 ★
0
3 ★
0
2 ★
0
1 ★
0
2 reviews
  • Fit Perfectly
    Larry —

    Restored all fridge and freezer functions, including temperature control.

  • Works Seamlessly
    Mark —

    Works perfectly restores full cooling and temperature control instantly.
